Automatic twist-off cap vacuum capping machine is designed to fully automatically capping twist-off cap with feed conveyor and orientation of the caps on the glass jar. Optional the machine can be equipped with an automatic labeller for sticking of self-adhesive labels on the cap or on the jar, by thermodater or laser marker for coding on the label.



Technical data

Output with vacuum: up to 1500 pcs/hour
Quantity of vacuum cappers: 2 pcs
Dimensions: on the picture
Weight: 520 kg
Power supply: 220-240V, 50 Hz
Power consumption: 1.2 kW
Air-pressure: 0.6 MPa
Сompressed air consumption: 500 liters/min

Options

Laminar-airflow-cabin
Rotary table for final assembly (1200 mm)

Advantage

Reliability
Easy maintenance
High quality vacuuming
