The machine is designed for filling the fresh cheese (curd) with different fat content and consistency with pieces of fruits or cheese pastes in pre-formed plastic cups of various shapes with sealing of pre-cut aluminum foil lids and capping with a plastic lid. Filler of this solution have a mixer with blades, auger and hopper.


Filling machine for curd (farmer cheese)

Technical data

Output with product:
Pneumatic drive – up to 1500 cups/hour
Electromechanical drive – up to 1800 cups/hour
Servo drive – up to 2000 cups/hour
Dimensions: 1040*1000*1800 mm
Weight: 380 kg
Power supply: 220-240V, 50 Hz
Power consumption: 1.2 kW
Air-pressure: 0.6 MPa
Сompressed air consumption: no more 250-300 liters / min


Set to another size of cups
Closing by plastic lids
Additional filler for two products in one cup
Enlarger on the top of hopper for feed of product ( up 150 kg) from trolley


High productivity
High accuracy of dosing
Vacuum-compensator (to prevent swelling of aluminium lids)
High quality sealing of pre-cut aluminium lids (tubular coiled heating element)
Fast change over of set to another size of cups
