The machine is designed for the filling of cottage cheese in pre-formed plastic cups and containers of various shapes with sealing of pre-cut aluminum foil lids and capping with a plastic lid. The important point for filling cottage cheese is saving of cheese grain, high accuracy of dosing and high productivity.

Cottage cheese filling machine



Technical data

Output with product:
Pneumatic drive – up to 1300 cups/hour
Dimensions: 1040*1000*1800 mm
Weight: 380 kg
Power supply: 220-240V, 50 Hz
Power consumption: 1.2 kW
Air-pressure: 0.6 MPa
Сompressed air consumption: no more 250-300 liters/min

Options

Additional filler for two products in one cup
Set to another size of cups
Closing by plastic lids

Advantage

Keep up cheese grain
High productivity
High accuracy of dosing
Vacuum-compensator (to prevent swelling of aluminium lids)
High quality sealing of pre-cut aluminium lids (tubular coiled heating element)
Fast change over of set to another size of cups
